Drafting a cable cross-section
  1. Home
  2. Products

Catalog & data sheets

Thirteen product families, one patented jacket technology. Open a family datasheet, or filter every specification in the 2026 catalog with the product selector.

Open the product selectorDownload 2026 catalog
LPI Cables Catalog 2026 cover

Complete catalog

LPI Cables Catalog 2026

All thirteen families with features, advantages and full spec tables. Every spec number links to its own specification sheet.

Download catalog (PDF)

STFOC

Where it all began. Patented LCP-jacketed cable for munitions tethers, ROV controls and littoral sensing, with a Non-Kink design that prevents hockling and continuous lengths up to 50 km.

Datasheet25 specs

Buoyant cable

From the thinnest 290 μm cable to 13 mm+ designs with multi-ton break strength, with precise density control for positive, neutral or negative buoyancy.

Datasheet36 specs

High strength cable

Non-buoyant cables with over 2,500 lbs breaking strength, a rugged exterior and continuous lengths over 5 km.

Datasheet44 specs

Hybrid cables

Copper and fiber integrated in a lightweight design: buoyant options, thin-wall insulation, Vectran strength members and 300 V, 600 V and 1,000 V ratings.

Datasheet128 specs

MicroTethers

Small-gauge copper and fiber in a lightweight tether, from 10.4 g/m designs for the smallest drones to 13,000 lbs work-load anchors for aerostats.

Datasheet97 specs

AVNOC avionic cable

Avionic Non-Kink Optical Cable that meets AS5382: a simple 3-layer extruded construction built to survive heat, vibration and extreme flexing.

Datasheet2 specs

Radiation hardened

RadHard fiber optic cables tested to ESCC 2263010, NASA-STD-8739.5 and SAE AS5382 for robust links in high radiation environments.

Datasheet15 specs

Patchcords

Harsh-environment patchcords that pair Linden cable constructions with industry-leading connectors, from deep ocean to outer space.

Datasheet

Phase stabilized STFOC

Specialty fiber that minimises the temperature dependence of transmission delay for synchronised measurement systems.

Datasheet5 specs

Precision wound spools

Fiber packs for subsea munitions and fly-by-fiber drones: a secure, non-jammable two-way link, with packs delivered up to 30 km long.

Datasheet

Gel-filled loose tube

A lightweight, flexible, cost-effective alternative to fiber-in-metal-tube for hybrid designs, from 1.6 mm to 3 mm OD.

Datasheet13 specs

Specialty copper

Light, temperature resistant, radiation hardened or buoyant copper cables from 3 mm to over 20 mm OD and 100 to 5,000 lbs work load.

Datasheet99 specs

Ribbon cables

Multi-channel ribbon with a robust buffering system and a compact profile, in telecom or +125 °C temperature ratings.

Datasheet7 specs

Cable Basics 101

A primer on fiber, conductors, strength members and jackets — useful before you specify.

Read the guide

Ribbon cables

One ribbon, two jackets

Colour-coded optical fibers locked in an acrylate binder layer, then sealed in the outer jacket that suits your environment.

PEI ribbon cable cutaway: PEI jacket, acrylate binder layer, colour-coded optical fibers
PEI jacketPolyetherimide outer jacket over the acrylate-bound fiber ribbon.
Fluoropolymer ribbon cable cutaway: fluoropolymer jacket, acrylate binder layer, colour-coded optical fibers
Fluoropolymer jacketFluoropolymer outer jacket over the same acrylate-bound fiber ribbon.
View ribbon specsRibbon datasheet

How to order

From spec number to delivered reel

Many cables are in stock. Custom short runs start at 300 m.

  1. Find a spec

    Filter the selector by family, fiber type, OD and tensile strength.

  2. Check the sheet

    Open the specification sheet for attenuation, weight, MBR and packaging.

  3. Request a quote

    Send the spec number, length and application — or describe what you need.

  4. Build & ship

    Every cable is serialised, with optical test data supplied with each shipment.

Precision wound fiber packs of different lengths
Precision wound packs, wound in Westford
Close-up of colour-coded fiber on the reel
Colour-coded fiber on the reel
Labelled spools packed for shipment
Serialised, labelled and packed to ship

Have an application in mind?

Tell us what the cable has to do — the environment, the load, the length — and our engineers will recommend a catalog cable or design one for you. Short runs from 300 m.

Request a quoteCall (978) 392-7985
